Retaining wall gravel backfill and geogrid rules
By My Yard Editorial Team · 7/28/2026
The Quick Answer
Backfill a minimum of 12 inches of clean 3/4-inch stone behind the wall face, and install geogrid every 2–3 courses on anything over 3 feet. Compact in 6–8 inch lifts.
The Witty Breakdown
Geogrid isn't optional decoration — it ties the wall into the soil mass behind it. Without it, tall walls rotate forward slowly for a decade and then quickly.
The stone chimney behind the wall relieves hydrostatic pressure. Clay backfill traps water and pushes.
Step-by-Step Fix
- 1
Excavate at least 12 inches behind the block face for the drainage zone.
- 2
Lay a perforated drain pipe at the base of the stone with outlets every 30–50 feet.
- 3
Roll geogrid the full designed embedment length — not just a token 2-foot strip.
- 4
Compact backfill in 6–8 inch lifts with a plate compactor.
Pro-Tip / Do Not Do This
Don't cut geogrid short to save material. The embedment length is the entire structural design; short grid is a wall on a timer.
